Remote setups

You can also save and recall setups via remote using the following SCPI commands:

• Save and recall user setups using *SAV and *RCL (Section 15).

• Restore GPIB defaults using *RST (Section 15).

• Restore bench defaults using :SYSTem:PRESet (Section 17).

• Save the power-on conﬁguration using :SYSTem:POSetup (Section 17).

Setting BENCH default GPIB default

Power-on default No effect No effect

Ranging (measure):

Auto range Enabled Enabled

Rel Off Off

Value 0.0 0.0

RS-232 No effect No effect

Source delay 3ms 3ms

Auto-delay Disabled Disabled

Speed Hi accuracy (10 PLC) Hi accuracy (10 PLC)

Sweep Linear staircase Linear staircase

Start 0V or 0A 0V or 0A

Stop 0V or 0A 0V or 0A

Step 0V or 0A 0V or 0A

Sweep count 1 1

Sweep Pts 2500 2500

Source ranging Best ﬁxed Best ﬁxed

Voltage protection NONE NONE

Triggered source:

Control Disabled Disabled

Scale factor +1.0 +1.0

Triggering:

Arm layer:

Event Immediate Immediate

Count 1 1

Output trigger Line #2, Off Line #2, Off

Trigger layer:

Event Immediate Immediate

Count 1 1

Output triggers Line #2, All off Line #2, All off

Delay 0.0 sec 0.0 sec

Table 1-3 (cont.)

Factory default settings
