17-12 SCPI Command Reference
Command Description
Default
parameter
SCPI
Source
memory
[:SENSe[1]]
:RESistance
:RANGe
[:UPPer]
<n>|UP|DOWN
[:UPPer]?
:AUTO <b>
:AUTO?
ULIMit <n>
ULIMit?
LLIMit <n>
LLIMit?
:NPLCycles <n>
:NPLCycles?
:AVERage
:AUTO <b>
:AUTO?
:COUNt <n>
:COUNt?
[:STATe] <b>
[:STATe]?
:ADVanced
:NTOLerance <NRf>
:NTOLerance?
[:STATe] <b>
[:STATe]?
:REPeat
:COUNt <n>
:COUNt?
[:STATe] <b>
[:STATE]:
:MEDian
:RANK <NRf>
:RANK ?
[:STATe] <b>
[:STATe]?
Configure measurement range:
Select range by specifying the expected
resistance reading.
1
Query range.
Enable or disable auto range.
Query auto range.
Set upper limit.
1
Query auto range upper limit.
Set lower limit.
1
Query auto range lower limit.
Specify integration rate (in line cycles):
0.01 to 10.
Query integration rate.
Path to configure moving and repeat filters:
Enable or disable auto filter.
Query state of auto filter.
Specify moving filter count; 1 to 100.
Query moving filter count.
Enable or disable moving filter.
Query state of moving filter.
Configure the advanced filter:
Set filter noise window (in %); 0 to 105.
Query filter noise window setting.
Enable or disable advanced filter.
Query state of advanced filter.
Confifgure the repeat filter:
Specify repeat filter count; 1 to 100.
Query repeat filter count.
Enable or disable repeat filter.
Query state of repeat filter.
Configure and control the median filter:
Specify median filter rank; 0 to 5.
Query median filter rank.
Enable or disable median filter.
Query state of median filter.
2.1e5
ON
Note 2
2.1e1
1.0
ON
1
ON
5
OFF
1
ON
0
ON
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
3
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Notes:
1. 0 to 2.1e13 with PreAmp. 0 to 2.1e7 without PreAmp.
2. 1e13 with PreAmp. 2.1e7 without PreAmp.
3. If auto ohms is enabled.
Table 17-5 (cont.)
SENSe command summary
To Next Page
