SCPI Command Reference 17-49
Grading mode status bit values:
Example reading string
The example ASCII reading string shown in Figure 17-1 shows a measure-
ment of a 10kΩ resistor, with the SourceMeter configured to Source I Mea-
sure V. The voltage reading is the voltage measurement (1.000236V), the
current reading is the current source value (100Ω), and the operation was
performed 72.826 seconds after the SourceMeter was turned on (or after
timestamp was reset). The status reading of 48,132 indicates that bits 2, 10,
11, 12, 13, and 15 of the status word are set.
Result Bit #: 21 20 19 9 8
Meas. Event
Status
1
All limits pass 0 0 0 0 0 Bit 5 (LP)
Limit test 1 fail 0 0 0 0 1 Bit 0 (L1)
Hi Limit test 2 fail 1 0 0 1 0 Bit 2 (HL2)
Lo Limit test 2 fail 0 0 0 1 0 Bit 1 (LL2)
Hi Limit test 3 fail 1 0 0 1 1 Bit 4 (HL3)
Lo Limit test 3 fail 0 0 0 1 1 Bit 3 (LL3)
Hi Limit test 5 fail 1 0 1 0 0 -
Lo Limit test 5 fail 0 0 1 0 0 -
Hi Limit test 6 fail 1 0 1 1 0 -
Lo Limit test 6 fail 0 0 1 1 0 -
Hi Limit test 7 fail 1 0 1 1 1 -
Lo Limit test 7 fail 0 0 1 1 1 -
Hi Limit test 8 fail 1 1 0 0 0 -
Lo Limit test 8 fail 0 1 0 0 0 -
Hi Limit test 9 fail 1 1 0 0 1 -
Lo Limit test 9 fail 0 1 0 0 1 -
Hi Limit test 10 fail 1 1 0 1 0 -
Lo Limit test 10 fail 0 1 0 1 0 -
Hi Limit test 11 fail 1 1 0 1 1 -
Lo Limit test 11 fail 0 1 0 1 1 -
Hi Limit test 12 fail 1 1 1 0 0 -
Lo Limit test 12 fail 0 1 1 0 0 -
1
See Section 14, Measurement Event Register and Figure 14-6 for details.
