Keithley 6430 User Manual

Status and Error Messages B-5
Number Error message Event
1
Status register
2
Bit
-105
-104
-103
-102
-101
GET not allowed
Data type error
Invalid separator
Syntax error
Invalid character
EE
EE
EE
EE
EE
Standard Event
Standard Event
Standard Event
Standard Event
Standard Event
5
5
5
5
5
-100 Command error EE Standard Event 5
+000 No error SE
+100
+101
+102
+103
+104
+105
+106
+107
+108
+109
+111
+112
+113
+114
Measurement events:
Limit 1 failed
Low limit 2 failed
High limit 2 failed
Low limit 3 failed
High limit 3 failed
Active limit tests passed
Reading available
Reading overflow
Buffer available
Buffer full
OUTPUT interlock asserted
Temperature limit exceeded
Voltage limit exceeded
Source in compliance
SE
SE
SE
SE
SE
SE
SE
SE
SE
SE
SE
SE
SE
SE
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
Measurement Event
0
1
2
3
4
5
6
7
8
9
11
12
13
14
+200
+300
+303
Standard events:
Operation complete
Operation events:
Device calibrating
Device sweeping
SE
SE
SE
Standard Event
Operation Event
Operation Event
0
0
3
1
EE = Error Event
SE = Status Event
SYS = System Error Event
2
Use following queries to read status registers:
Standard Event: *ESR?
Operation Event: STAT:OPER?
Measurement Event: STAT:MEAS?
Questionable Event: STAT:QUES?
Table B-1 (cont.)
Status and error messages

Keithley 6430 Specifications

General

Type	Sub-Femtoamp Remote SourceMeter
Compliance Voltage	200 V
Maximum Output Voltage	200 V
Maximum Output Current	100 mA
Compliance Limit	Programmable
Interface	GPIB, RS-232
Input Impedance	>10^14 Ω
