Multiple responses are separated by commas. If more than one channel has been queried, all the DAC
values for the first channel are returned, followed immediately by the DAC values of the next channel.
Parameter Typical Return
<"name"> the table name None
<chanlist> one or more channels <4.8,4.9,5.0,5.1,5.2,5.3, ...>
Returns the DAC table settings on channel 2: VOLT:DTAB:TABL? "table1", (@2)
[SOURce:]VOLTage:DTABle:TABLe[:IMMediate]:VMP? <"name">, (@<chanlist>)
Returns the calculated Vmp (maximum power voltage) of the internal DAC table for the specified table.
Multiple responses are separated by commas. If more than one channel has been queried, all the DAC
values for the first channel are returned, followed immediately by the DAC values of the next channel.
Parameter Typical Return
<"name"> the table name None
<chanlist> one or more channels +3.620843E+00
Returns the calculated Vmp of the DAC table on channel 2: VOLT:DTAB:TABL:VMP? " table1", (@2)
[SOURce:]VOLTage:DTABle:TABLe[:IMMediate]:VOC? <"name">, (@<chanlist>)
Returns the calculated Voc (open-circuit voltage) of the internal DAC table for the specified table.
Multiple responses are separated by commas. If more than one channel has been queried, all the DAC
values for the first channel are returned, followed immediately by the DAC values of the next channel.
Parameter Typical Return
<"name"> the table name None
<chanlist> one or more channels +5.10000E+00
Returns the calculated Voc of the DAC table on channel 2: VOLT:DTAB:TABL:VOC? "table1", (@2)
[SOURce:]VOLTage:PROTection[:LEVel] <value>|MIN|MAX, (@<chanlist>)
[SOURce:]VOLTage:PROTection[:LEVel]? [MIN|MAX,], (@<chanlist>)
Sets the over-voltage protection level. Units are in volts. If the output voltage exceeds the OVP level,
the output is disabled and the Questionable Condition status register OV bit is set.
Parameter Typical Return
0
to
120%
of
rating,
*RST
120%
of
rating
<protect
level>
<chanlist> one or more channels
Sets the over-voltage protection to 24 V: VOLT:PROT 24, (@2)
5 SCPI Programming Reference
144 Keysight MP4300 Series Operating and Service Guide
