Triggers 11
Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide 195
The following table lists the line (or count) numbers per field for each video
standard.
The following table lists the line numbers for each EDTV/HDTV video standard
(available with the DSOX3VID extended video triggering license).
Video Triggering
Examples
The following are exercises to familiarize you with video triggering. These exercises
use the NTSC video standard.
• “To trigger on a specific line of video" on page 196
• “To trigger on all sync pulses" on page 197
• “To trigger on a specific field of the video signal" on page 198
• “To trigger on all fields of the video signal" on page 199
• “To trigger on odd or even fields" on page 200
To set up Generic video triggers
When Generic (available with the DSOX3VID extended video triggering license) is
selected as the Video trigger Standard, you can trigger on custom bi-level and
tri-level sync video standards. The Video Trigger Menu changes as follows.
Video standard Field 1 Field 2 Alt Field
NTSC 1 to 263 1 to 262 1 to 262
PAL 1 to 313 314 to 625 1 to 312
PAL-M 1 to 263 264 to 525 1 to 262
SECAM 1 to 313 314 to 625 1 to 312
EDTV 480p/60 1 to 525
EDTV 567p/50 1 to 625
HDTV 720p/50, 720p/60 1 to 750
HDTV 1080p/24, 1080p/25, 1080p/30,
1080p/50, 1080p/60
1 to 1125
HDTV 1080i/50, 1080i/60 1 to 1125
