330 Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide
20 Save/Email/Recall (Setups, Screens, Data)
• The Entry knob. Turn the knob to select a key in the dialog; then, push
the Entry knob to enter it.
• A connected USB keyboard.
• A connected USB mouse — you can click anything on the screen that can be
touched.
4 When you are done entering the file name, select the dialog's Enter or OK key
or press the File Name softkey again.
The file name appears in the softkey.
5 When available, the Increment softkey can be used to enable or disable
automatically incremented file names. Auto increment adds a numeric suffix to
your file name and increments the number with each successive save. It will
truncate characters as necessary when the file name length is at maximum and
more digits are required for the numeric portion of the file name.
Emailing Setups, Screen Images, or Data
You can send oscilloscope files over the network via e-mail. You can e-mail any file
that can be saved.
To e-mail a setup, screen image, or data file:
1 Make sure the oscilloscope is connected to the local area network (see “To
establish a LAN connection" on page 343).
2 Press the [Save/Recall] key.
3 In the Save/Recall Menu, press Email.
4 In the Email Menu, press Format; then, select the type of file you want to send.
You can select from the same formats that are available when saving files.
Settings for the selected format are also the same. See “Saving Setups, Screen
Images, or Data" on page 321.
5 Press the Attachment Name softkey and use the keypad dialog to enter the name
of the attachment file that will be sent.
6 In the e-mail configuration dialog box, touch the To, From, Server, and Subject
fields and use the keypad dialog to enter the appropriate strings.
