Getting Started 1
Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide 61
Access the Built-In Quick Help
To view Quick Help 1 Press and hold the key or softkey for which you would like to view help.
Sidebar
information and
controls area
The sidebar information area can contain summary, cursors, measurements, or
digital voltmeter information dialogs or it can contain navigation and other
control dialogs.
For more information, see:
• “Select Sidebar Information or Controls" on page 49
• “Undock Sidebar Dialogs by Dragging" on page 49
Menu line This line normally contains menu name or other information associated with the
selected menu.
Softkey labels These labels describe softkey functions. Typically, softkeys let you set up
additional parameters for the selected mode or menu.
Pressing the Back/Up key at the top of the menu hierarchy turns off softkey
labels and displays additional status information describing channel offset and
other configuration parameters.
