Keysight InfiniiVision 3000T X-Series Oscilloscopes
User's Guide
2 Horizontal Controls
To adjust the horizontal (time/div) scale / 64
To adjust the horizontal delay (position) / 65
Panning and Zooming Single or Stopped Acquisitions / 66
To change the horizontal time mode (Normal, XY, or Roll) / 67
To display the zoomed time base / 71
To change the horizontal scale knob's coarse/fine adjustment setting / 72
To position the time reference (left, center, right, custom) / 72
Searching for Events / 73
Navigating the Time Base / 75
The horizontal controls include:
• The horizontal scale and position knobs.
•The [Horiz] key for accessing the Horizontal Menu.
• The zoom key for quickly enabling/disabling the split-screen zoom display.
•The [Search] key for finding events on analog channels or in serial decode.
•The [Navigate] keys for navigating time, search events, or segmented memory
acquisitions.
• Touchscreen controls for setting the horizontal scale and position (delay),
accessing the Horizontal Menu, and navigating.
The following figure shows the Horizontal Menu which appears after pressing the
[Horiz] key.
