ENGLISH
112
DVR User’s Manual
Model 4CH 8CH 16CH
Video Format NTSC or PAL
Linux
Video
Input / Output
4 BNC Inputs /
1 VGA Output,
2 BNC Outputs
8 BNC Inputs /
1 VGA Output,
2 BNC Outputs
16 BNC Inputs /
1 HDMI Output,
1 VGA Output,
2 BNC Outputs
Video Compression H.264
Audio
Input / Output 1 RCA Input / 1 RCA Output
16 BNC Inputs /
2 BNC Outputs
Audio Compression 8kHz x 16bit ADPCM
Display
NTSC: 704 x 480, PAL: 704 x 576
Frame Rate
NTSC: 120fps
PAL: 100fps
NTSC: 240fps
PAL: 200fps
NTSC: 480fps
PAL: 400fps
Recording
NTSC: CIF(352x240) / HD1(704x240) / D1(704x480)
PAL: CIF(352x288) / HD1(704x288) / D1(704x576)
Frame Rate
NTSC: 120fps-D1 / 120fps-
HD1 / 120fps-CIF
NTSC: 60fps-D1 /
120fps-HD1 / 240fps-CIF
NTSC: 120fps-D1 /
240fps-HD1 / 480fps-CIF
PAL: 100fps-D1 / 100fps-
HD1 / 100fps-CIF
PAL: 50fps-D1 / 100fps-HD1
/ 200fps-CIF
PAL: 100fps-D1 / 200fps-
HD1 / 400fps-CIF
Modes
Always / Schedule / Moon Detecon/
Sensor Triggered / Remote Recording
Always / Schedule / Moon Detecon / Remote Recording
Recording Pack Time 15/30/45/60 mins Selectable
HDD
Interface 1 SATA Fixed HDD Rack
1 SATA Fixed HDD Rack
and 1SATA Removable
HDD Rack
Capability Up to 2TB
Playback
Search Time & Date / Event List / Time Bar
Channel
Max. 4 CH Simultaneous
Playback
Max. 8CH Simultaneous
Playback
Max. 16CH Simultaneous
Playback
Mode Play, Fast Forward, Fast Rewind, Frame by Frame
Network
Network Interface RJ45, 10M/100M, Supports TCP/IP, DHCP, DDNS, PPPOE
IE and Safari Browser Supported
