[4] Move the DRIVE ROLLER to the non-drive
Replacement of the Resilient Drive Roller
side and remove the KEY from the
in the Developer and Fixer Racks
SPROCKET.
[5] Pull the SHAFT to the drive side to remove it
[1] Remove the 2 SPRINGS from the top of the
from the non-drive SIDE PLATE.
RACK.
[6] Remove the THRUST WASHER, SPROCKET,
[2] Remove the SCREWS, WASHERS, LOCK
and SPACER.
WASHERS, GEAR, SPACERS, and
BEARINGS from the resilient DRIVE ROLLER
[7] Continue to pull the SHAFT to the non-drive
on the outside of both SIDE PLATES.
side.
[3] Rotate the flat part of the SHAFT to the up
[8] Remove the DRIVE ROLLER.
position.
[9] Reverse the procedure to install the new
DRIVE ROLLER.
H112_0106DA
H112_0106DCA
SPACER
BEARING
WASHER
SCREW
WASHER
LOCK
SPRING
SIDE PLATE
non-drive
SIDE PLATE
drive
BEARING
SPACER
WASHER
WASHE
R
LOCK
SCREW
KEY
GEAR
DRIVE
SPRING
WASHER
THRUST
KEY
SPROCKET
SPACER
ROLLER
DRIVE
SHAFT
SPACER
Replacement of the Resilient Drive Roller
