Kodak M35 - Main Drive

Main Drive
Adjustment of the Main Drive Chain
Moving parts.
Do not overtighten the DRIVE CHAIN.
[1] Disconnect the main power.
[4] Move the MOTOR up or down until the
[2] Remove the:
DRIVE CHAIN is tight. Do not overtighten the
DRIVE CHAIN.
• drive SIDE PANEL
• 2 GUARD SCREWS [5] Tighten the 4 MOUNTING SCREWS.
• the CHAIN GUARD
[6] Install the:
• MOTOR CAGE
• MOTOR CAGE
• 2 SCREWS
• 2 SCREWS
[3] Loosen the 4 MOUNTING SCREWS.
• CHAIN GUARD
• 2 GUARD SCREWS
• SIDE PANEL.
H112_0102BA
H112_0102BCA
(4)
SCREW
MOUNTING
CAGE
MOTOR
SCREW (2)
MOTOR
CHAIN
DRIVE
(2)
SCREW
GUARD
GUARD
CHAIN
Adjustment of the Main Drive Chain
981777 2-17
