7.6 Mains filters 3NF-07...30
Observe the safety instructions ➜ p. 28.
Technical Data
Type Nom.
Current*
A
[mm]
B
[mm]
C
[mm]
D
[mm]
F
[mm]
G
[mm]
M
[mm]
P
[mm]
Weight
[kg]
Terminals PE
Bolt
3NF-07 7 A 190 40 70 160 180 20 4.5 180 0.5 4mm²,
0.7..0.8Nm
M5,
2.2Nm
3NF-16 16 A 250 45 70 220 235 25 5.4 240 0.8
3NF-30 30 A 270 50 85 240 255 30 5.4 260 1.2
10mm²,
1.9..2.2Nm
* at 50°C environment temperature
Accessories Europe | 7 Mains filters
Kollmorgen | December 2014 31
