Accessories Europe | 11 Cables
11.11.2.7 Order codes motor cables for AKD-B/P/T/M
Hybrid cables for motors with one-cable connection ➜ p. 62
Define the required length in clear text (steps of 1m). Length definition vvv=meters. Max-
imum cable length 50 m, in case of cable length ≥ 25 m a motor choke (➜ p. 41) should be
used.
AKD-B/P/T/M, AKM1 motor connector y-tec
Usable to connect AKD-x00306* and AKM1 (connector options 1, Y).
Cable is delivered with shield clamp.
Article Order code
Motor cable (4x1) CM01A3-010-vvv-00
Motor cable (4x1+(2x1)) CM11A3-010-vvv-00
*= x means variants -B, -P, -T and -M
AKD-B/P/T/M, AKM1 motor connector y-tec
Usable to connect AKD-x00307* and AKM1 (connector options 1, Y).
Drive connector with mounted shield plate.
Article Order code
Motor cable (4x1) CM02A3-010-vvv-00
Motor cable (4x1+(2x1)) CM12A3-010-vvv-00
*= x means variants -B, -P, -T and -M
72 Kollmorgen | December 2014
