Accessories Europe | 11 Cables
11.5 24V auxiliary voltage supply
Connectors are used, that are included in the delivery package of the servo amplifiers. If
necessary, the connectors are coded and printed with the corresponding terminal des-
ignation.
We do not deliver configured cables for this interface.
You must always observe the specifications in respect of cable cross-sections contained in
the instructions manual for the servo amplifier you are using in your application. Fit suitable
wire end ferrules or plug connectors to stripped conductors. A connection diagram appears in
the servo amplifier instructions manual.
11.5.1 Mating connector (part of delivery)
Amplifier Connector Order Code
S300 X4 DE-107555
S400 X0 DE-102583
S601...620 X4 DE-90062
S640/670 X4 DE-92143
S701...724 X4A DE-200449
S701...724 X4B DE-200450
S748/772 X4 DE-201241
S748/772 X9B DE-201193
AKD-B/P/T/M X1 CON-AKDX1-SL
AKD-C X13 Connector Kit ➜ p. 23
11.5.2 Recommended cable type
Purpose recommended cable
24V Aux. Voltage
Observe voltage drop!
H07V-K 1.5 or H07V-K 2.5
52 Kollmorgen | December 2014
