11 Cables
Kollmorgen assumes no liability for errors or damage to equipment caused by cables man-
ufactured by customers.
11.1 Technical data for cables
Information on the chemical, mechanical and electrical characteristics of the cables can be
found in our Technical WIKI (Cables).
Insulation material
Sheathing: PUR (polyurethane, code 11Y)
Core insulation: PETP (polyesteraphthalate, code 12Y)
Capacitance (phase to shield)
Motor cable: less than 180 pF/m (cross sections >6mm² have larger capacitance)
Feedback cable: less than 120 pF/m
Hybrid Cable: special requirements
Technical data
l The brackets in the core definition indicate the shielding
l All cables are suitable for use as trailing cables
l The technical data refer to use as moveable cables
l Operating life : 10 million bending cycles
l All cables are UL recognized
11.2 Tools
Only work with the special tools that are required for the used connectors. You can obtain
these special tools from the manufacturer of the connectors or contacts.
Accessories Europe | 11 Cables
Kollmorgen | December 2014 45
