Accessories Europe | 5 îîShield clamps
5 Shield clamps
You must read the instructions manuals for the servo amplifier/servo motor you are using in
your application. Observe the safety instructions they contain before commencing mount-
ing/installation work.
5.1 Auxiliary terminals on the servo amplifier
S300, S701...724 and AKD
These servo amplifiers feature slots on the front panel for the connection of
additional shield clamps.
Article Tension range Order Codes
SK14 6-13mm DE-108248
S640/670, S748/772
The shroud supplied with these servo amplifiers features
slots for the connection of additional shield clamps.
We recommend using the following shield clamp:
Manufacturer Article Tension
range
OBO (Bettermann) BBS-Schelle Typ 2056 16-22mm
OBO (Bettermann) BBS-Schelle Typ 2056 28-34mm
The clamps are part of delivery of the servo amplifier.
24 Kollmorgen | December 2014
