Kollmorgen SERVOSTAR 400 User Manual

Accessories Europe | 8 Brake resistors
8.3 Type assignment and order codes
Servo amplifier Brake resistor
Resistance/Ω
Remarks
S300 (S3xx61) BAR(U) 66 optional
S300 (S3xx01) BAR(U) 91 optional
S400, S601...620, S701-712 BAR(U) 33 optional
S640, S748 BAS(U) 15 usually required
S670, S772 BAS(U) 10 usually required
S724 BAR(U)/BAS(U) 23 optional
AKD-x00306* BAFP(U)/BAR(U)/BAS(U) 33 usually required
AKD-x00606* BAFP(U)/BAR(U)/BAS(U) 33 usually required
AKD-x01206* BAR(U)/BAS(U) 15 optional
AKD-x02406* BAR(U)/BAS(U) 15 optional
AKD-x00307* BAR(U)/BAS(U) 33 optional
AKD-x00607* BAR(U)/BAS(U) 33 optional
AKD-x01207* BAR(U)/BAS(U) 33 optional
AKD-x02407* BAR(U)/BAS(U) 23 optional
AKD-x04807* BAS(U) 10 optional
AKD-C01007 BAR(U)/BAS(U) 33 optional
Order codes
Article Amplifier Resis-
tance
[Ω]
Rated
Power
[W]
Max.
Power
[W]
Order code
Brake resistor BAS(U) 2000-10 S670,S772,
AKD-x04807
10 2000 3200 DE-103874
Brake resistor BAS(U) 3000-10 10 3000 4800 DE-103875
Brake resistor BAS(U) 6000-10 10 6000 9600 DE-103876
Brake resistor BAR(U) 500-15 AKD-x01206 & x02406,
S640, S748
15 500 800 DE-201439
Brake resistor BAR(U) 1000-15 15 1000 1600 DE-201440
Brake resistor BAS(U) 2000-15 15 2000 3200 DE-103871
Brake resistor BAS(U) 3000-15 15 3000 4800 DE-103872
Brake resistor BAS(U) 6000-15 15 6000 9600 DE-103873
Brake resistor BAR(U) 600-23 AKD-x02407, S724 23 600 960 DE-200613
Brake resistor BAR(U) 1000-23 23 1000 1600 DE-200614
Brake resistor BAS(U) 2000-23 23 2000 3200 DE-200615
Brake resistor BAS(U) 3000-23 23 3000 4800 DE-200616
Brake resistor BAS(U) 4000-23 23 4000 6400 DE-200617
Brake resistor BAFP(U) 100-33 AKD-x00306 to -x00606
AKD-x00307 to -x01207,
AKD-C01007, S400,
S601...620, S701-712
33 100 160 DE-201437
Brake resistor BAFP(U) 200-33 33 200 320 DE-201438
Brake resistor BAR(U) 250-33 33 250 400 DE-106254
Brake resistor BAR(U) 500-33 33 500 800 DE-106255
Brake resistor BAR(U) 1500-33 33 1500 2400 DE-106258
Brake resistor BAS(U) 3000-33 33 3000 4800 DE-201407
Brake resistor BAR(U) 300-66 S300 (S3xx61) 66 300 480 DE-107161
Brake resistor BAR(U) 600-66 66 600 960 DE-107162
Brake resistor BAR(U) 1000-66 66 1000 1600 DE-107163
Brake resistor BAR(U) 300-91 S300 (S3xx01) 91 300 480 DE-107164
Brake resistor BAR(U) 600-91 91 600 960 DE-107165
Brake resistor BAR(U) 1000-91 91 1000 1600 DE-107166
*= AKD-x means AKD variants -B, -P, -T and -M
34 Kollmorgen | December 2014
