11.6.3 Digital/analog I/O for S300/S400/S600/S700 and AKD-B/P/T/M
The cables for analog signals must be twisted pairs, and shielded. The digital signals can be
connected by single wires.
We do not deliver configured cables for this interface.
Mating connector (part of delivery)
Digital / analog signals STO Signals
Amplifier # Order Code # Order Code # Order Code
S300 X3 DE-107554 - - X4 DE-107555
S400 X3 DE-102585 X1 DE-102584 - -
S601...620 X3 DE-90061 - - X10 DE-101696
S640/670 X3 DE-101695 - - X10 DE-101696
S701...724 X3A DE-200447 X3B DE-200448 X4B DE-200450
S748/772 X3A DE-200447 X3B DE-200448 X4 DE-201241
AKD-B/P/T X7 CON-AKDX7-SL X8 CON-AKDX8-SL X1 CON-AKDX1-SL
AKD-T-IC X7 CON-AKDX7-SL X8 CON-AKDX8-SL X1 CON-AKDX1-SL
X21 CON-AKDX21-SL X22 CON-AKDX22-SL - -
X23 CON-AKDX23-SL X24 CON-AKDX24-SL - -
AKD-M X7 CON-AKDX7-SL X8 CON-AKDX8-SL X1 CON-AKDX1-SL
X35 CON-AKDX35-SL X36 CON-AKDX36-SL - -
Recommended cable type
Purpose max. length recommended cable
Digital I/O 10m H07VK 0,5
BTB 10m
Digital GND 10m
Analog Setpoint 25m LiYCY (TP) 4x2x0.25
Analog GND 25m
Color code for shielded cable
Signal Color* Cable
AGND GY
LiYCY (TP) 4x2x0.25
analog in 1+ WH
analog in 1- BN
analog in 2+ GN
analog in 2- YE
analog out 1 PK
analog out 2 BU
AGND RD
* according to IEC 60757
Accessories Europe | 11 Cables
Kollmorgen | December 2014 55
