COMMON RAIL SYSTEM
07-CR-E5,07-CR-TE5,07-CR-TIE5, DM
1-S120
9Y3200007CRS0156US0
Name Exhaust gas temperature sensor (T
2
) Emergency high
ISO 14229
P-Code
P3004
J1939-73
SPN 3246
FMI 0
SPN Name
SAE J1939 Table C1
Aftertreatment 1 Exhaust Gas
Temperature 3 Preliminary FMI
DTC Name
Emergency
Exhaust gas temperature sensor 2: High
Detection item Exhaust gas temperature (T
2
) high
DTC Set
Preconditions
Exhaust gas temperature sensor T
0
,T
1
and T
2
are normal
Battery voltage is normal
DTC set parameter DPF outlet temperature (T
2
): 820 °C (1508 °F) or more
Time to action or
number of error
detection
2.0 sec. or more
Limp Home Action
by engine ECU
(system action)
Stop injection (Q = 0 mm
3
/st)
Engine stop
•EGR stop
Intake throttle 0 % open (Close)
Inhibit starter relay activation until exhaust gas temperature reduces down to 300 °C
(572 °F)
Behaviour During
Malfunction
Engine stops
Inhibitef cranking until down to 300 °C (572 °F)
Engine Warning
Light
•ON
Recovery from
error
Under 300 °C (572 °F) & key switch turn OFF
Delay time for
recovery
Remark
In case engine ECU is not involved to drive starter, starter activation should be inhibited
by other way until exhaust gas temperature reduces down to 300 °C (572 °F)
KiSC issued 03, 2022 A
