Kubota MX6000 - Page 108

To Next Page

To Previous Page

(1) Air

(2) Water

(A) Correct

(B) Incorrect

Correct Incorrect

Amount of water

75% of full capacity

of tire

100% of full capacity

of tire

Characteristic

Air compresses like

a cushion

Water can not be

compressed

TIRES, WHEELS, AND BALLAST BALLAST

104

MX5400,MX6000
