2. Air control vent
2.1 Front air outlet
You can adjust the front air outlets independently as
required.
To defrost the windshield, rotate the front air outlets
toward the windshield.
(1) Front air outlet (A) Open
(B) Closed
(C) Windshield
2.2 Side air outlet
You can adjust the side air outlets to direct the air on to
the operator, the door and window, or the rear of the
CAB.
(1) Side air outlet
2.3 Door air outlet
You can adjust the door-air-outlets to direct the air on to
the operator, the door and window, or the rear of the
CAB.
(1) Door air outlet
NOTE :
• If the airflow rate at the face is too low, close
the door-air-outlet.
2.4 Recirculation / fresh air selection lever
Fresh air
Set the recirculation / fresh air selection lever to
the position. Fresh air will flow into the CAB.
Fresh air is helpful when you work in dusty con-
ditions or if the glass windows get foggy.
Recirculation
Set the recirculation / fresh air selection lever to
the position. The in-CAB air will be recircu-
lated. The in-CAB air is useful for cooling or
heating the CAB quickly or keeping it extra cool
or warm.
NOTE :
• When heating, do not keep the recirculation /
fresh air selection lever at the
position for a
long time. The windshield easily gets foggy.
• While working in a dusty conditions, keep the
recirculation / fresh air selection lever at the
position. The in-CAB air increases the pressure
in the CAB, which helps prevent dust from
coming into the CAB.
CAB OPERATION AIR CONDITIONER
