Kubota MX6000 - Cleaning the Inner Air Filter [CAB Type]; Cleaning the Fresh Air Filter [CAB Type]

5. Attach the snap ring of the tie-rod joint.
(1) Snap ring
(2) Tie-rod nut
(3) Tie-rod joint
[A] 4WD
[B] 2WD
Tie-rod nut (2)
Tightening
torque
4WD
167 N⋅m to 196 N⋅m
(17 kgf⋅m to 20 kgf⋅m)
[123.2 lbf⋅ft to 144.6 lbf⋅ft]
2WD
83.3 N⋅m to 88.2 N⋅m
(8.5 kgf⋅m to 9.0 kgf⋅m)
[61.4 lbf⋅ft to 65 lbf⋅ft]
3. Cleaning the inner air filter [CAB
type]
1. Remove the inner-air-filter.
2. Blow air from the direction opposite to the normal
air flow of the inner-air-filter.
Pressure of compressed air must be as follows.
Pressure of compressed air
Under 205 kPa (2.1 kgf/cm
2
)
[30 psi]
(1) Inner air filter
4. Cleaning the fresh air filter [CAB
type]
1. Remove the knob bolts and pull out the fresh-air-
filter.
(1) Fresh air filter
(2) Cover
(3) Knob bolt
(A) Air inlet port
NOTE :
• Attach the fresh-air-filter and cover as the
preceding illustration.
SERVICE EVERY 200 HOURS PERIODIC SERVICE
MX5400,MX6000
139
