6. Tachometer
The tachometer gives readings for the engine speed
and PTO-shaft-speed.
The tachometer indicates the engine speed and the
location of 540-PTO-shaft-speed on the dial.
(1) Engine revolution (A) PTO (540 rpm)
PARKING THE TRACTOR
When parking the tractor, be sure to set the parking
brake.
WARNING
To avoid personal injury or death:
Before dismounting the tractor
• Always set the parking brake and lower all
implements to the ground.
• Leaving the transmission in gear with the
engine stopped will not prevent the tractor with
HST transmission from rolling [HST type].
• Stop the engine and remove the starter key.
Before getting off the tractor, perform the proper
procedure.
1. Disengage the PTO.
(See PTO clutch control switch on page 83)
(1) PTO clutch control switch
(A) Push
(B) On (Engaged)
(C) Off (Disengaged)
2. Lower all implements to the ground.
(See Position control of 3-point hitch mounted
implement on page 91)
(1) Position control lever
(2) Draft control lever (if equip-
ped)
(A) Up
(B) Down
(C) Float
3. Place all control levers in their neutral positions.
4. Set the parking brake.
(See To set the parking brake on page 44)
[Manual transmission type]
[HST type]
(1) Brake pedal
(2) Parking brake lever
(A) Interlock the brake pedals
(B) Depress
(C) Pull
CHECK DURING DRIVING OPERATING THE TRACTOR
