IMPLEMENT LIMITATIONS
IMPLEMENT LIMITATION TABLES
IMPORTANT :
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved
by KUBOTA. Do not use the following implements:
• Implements which are not sold or approved by KUBOTA
• Implements which exceed the maximum specifications listed in the following table
• Implements which are otherwise unfit for use with the KUBOTA Tractor
Preceding implements may result in malfunctions or failures of the tractor, damage to other property, and
injury to the operator or others.
NOTE :
KUBOTA does not cover any malfunctions or failures of the tractor resulting from use with improper
implements by the warranty.
MX5400 MX6000
Max. width of tread with farm tires
Front
2WD
1530 mm
(60.2 in.)
---
4WD
1325 mm
(52.2 in.)
1325 mm
(52.2 in.)
Rear
1490 mm
(58.7 in.)
1490 mm
(58.7 in.)
Lower link end max. loading weight (W0)
1300 kg
(2870 lbs.)
1300 kg
(2870 lbs.)
Actual figures
Implement weight (W1) and/or size As in the following list (Shown on the next table)
Max. Drawbar Load (W2) 750 kg (1650 lbs.)
Max. capacity of trailer loading weight (W3)
4300 kg
(9480 lbs.)
W0
Lower link end maximum hydraulic lifting capacity weight
W1
Implement weight. The weight of the implement which can be put on the lower link
W2
Maximum drawbar load
W3
Trailer loading weight. The maximum loading weight for trailer (with trailer's weight)
NOTE :
• Implement size may vary depending on soil conditions where you operate the machine.
• Strictly follow the instructions outlined in the operator’s manual of the mounted or trailed machinery or
trailer, and do not operate the combination tractor-machine or tractor-trailer unless all instructions have
been followed.
• When you use the forestry application, there are following hazards:
– toppling trees, primarily in case a rear-mounted-tree-grab-crane is mounted at the rear of the tractor
IMPLEMENT LIMITATION TABLES IMPLEMENT LIMITATIONS
