KurzB‐SeriesOperationsGuide 4–33
Program ModeAdvanced Setup
Option 14 — Recalibrating the 4-20 mA Outputs
Anexternalammetermustbeconnectedtotheflowmeter’sanalogoutputsandmatchthe4.0
mAand20mAsignalsgeneratedbytheflowmeter.Thearrowkeysareusedtolowerorraisethe
outputuntileachconditionmatches.
ToaccesstheCalibrationOutputsmenuinProgrammode:
1> PressP.
2> EntertheAdvancedaccesscode,andthenpressE.
3> Press 2toinvoketheQuickJumpoption.
4> Press14fortheCalibrateOutputsmenu,andthenpressE.
SET 4.000 mA TO
OUT 1 UP=^ DN=v
Thesetupforthelowerendofoutput1appears.
5> PresstheupordownkeytomatchthemAvaluewiththeammeter.PressE.
SET 20.000 mA TO
OUT 1 UP=^ DN=v
Thesetupfortheupperendofoutput1appears.
6> PresstheupordownkeytomatchthemAvaluewiththeammeter.PressE.
AO1 SLOPE 0.99
AO1 OFFSET -0.02
Theslopeandoffsetforoutput1appears.
7> PressE.
SET 4.000 mA TO
OUT 2 UP=^ DN=v
Thesetupforthelowerendofoutput2appears.
8> PresstheupordownkeytomatchthemAvaluewiththeammeter.PressE.
SET 20.000 mA TO
OUT 2 UP=^ DN=v
Thesetupfortheupperendofoutput2appears.
