KurzB‐SeriesOperationsGuide4–34
Program ModeAdvanced Setup
9> PresstheupordownkeytomatchthemAvaluewiththeammeter.PressE.
AO2 SLOPE 1.00
AO2 OFFSET -0.00
Theslopeandoffsetforoutput2appears.
10> PressE.
CHK NE-43 ALARMS
>YES ^v
TheCheckNE‐43Alarmspromptappears.
11> UsethearrowkeystoselectYESandthenpressE.
LOW ALARM CHECK
IOUT <# 3.6 mA
TheNE‐43lowalarmsignal,lessthanorequalto3.6mA,issenttotheanalogoutput
channel.Confirmtheoutputlevelwiththereferenceammeter.
12> PressE.
HIGH ALARM CHECK
IOUT ># 21.0 mA
TheNE‐43highalarmsignal,greaterthanorequalto21.0mA,issenttotheanalog
outputchannel.Confirmtheoutputlevelwiththereferenceammeter.
13> PressE.
ENTER OUTPUT
>12.4000000 mA
TheEnterOutputpromptallowsyoutospecifyasignalleveltheflowmetersendsto
theanalogoutputchannels.
14> UsethenumberanddecimalkeystochangethevalueandthenpressE.
12.400 mA
1.891 V
15> PressE,C,orPtoreturntotheProgrammodeoptionmenu.
