KurzB‐SeriesOperationsGuide 4–57
Program ModeAdvanced Setup
Option 22 — Manual PID Adjustments
BeforemakingchangesintheManualPIDControlmenu,theactivestateofPIDmustbeturned
ONandtheManualoptionenabled,asspecifiedin“Option21—SettingUpPIDData”.Automatic
modestartsaPIDcontrolactionassoonasyouspecifytheautomaticsetting.
Note Use Display mode to view Option 41, External Input Current, for value
information.
Undermanualcontrol,youcanadjustthePIDoutputor4‐20mApositionsignals.Theflowrateor
velocityismaintainedtothePIDsetpointvalue.
ToaccesstheManualPIDControlmenuinProgrammode:
1> PressP.
2> EntertheAdvancedaccesscode,andthenpressE.
3> Press 2toinvoketheQuickJumpoption.
4> Press22fortheManualPIDControlmenu,andthenpressE.
WhentheflowmeterisconfiguredwiththePIDfunction,thePIDstateisON,andPID
operationissettoManual,thefollowingpromptappears.
OUT= 0 PERCENT
^=OPEN v=CLOSE
5> Pressthearrowkeystoopen(increase)orclose(decrease)theoutput,andthenpressH.
— 100percentisthemaximumPIDlimitequivalenttothemaximumoutputcurrentis
reached.
— 0percentistheminimumPIDlimitequivalenttotheminimumoutputcurrentis
reached.
