KurzB‐SeriesOperationsGuide1–12
B‐SeriesFlowMeterModes & Menus
13
(con’t)
GasName
#VMDataSets(x)
GasMolWt
NewRefDensity
Thisisvelocity
temperature
mapping.
FlowDataforS1
#DataPtsAtS1(x )
RawSignalS1‐1
FlowDataS1‐1
RawSignalS1‐x
FlowDataS1‐x
(RawSignalandFlowDatarepeat)
Flow
DataforSx(optional)
#DataPtsatSx(n)
RawSignalSx‐1
FlowDataSx‐1
RawSignalSx‐n
FlowDataSx‐n
(RawSignalandFlowDatarepeat)
14 CALIBAOUT CalibrateAnalogOutputs
Set4.000mAtoOut1()
Set20.000
mAtoOut1()
AO1CalibCoeff
A01Slope
A01Offset
Set4.000mAtoOut2()(optional)
Set20.000mAtoOut2()(optional)
Thiscalibratesthe
digital‐to‐analog
converterthat
generatesthe
4‐20mAsignal
output.
AO2CalibCoeff(optional)
A02Slope
A02Offset
Chk
NE‐43Alarms
YES NO
IfYES
LowAlarmCheck
HighAlarmCheck
EnteroutputmA
mAandequivalent
15 VRMSDATA VariableFlowCorrectionData()
Enter#ofFlowDataSetsn
EnterFlowDataSet#x
RefValueRx(Vrms‐x)
TestDataDx (VdsAve‐x)
Thisshouldonly
be
changedwith
approvalfromKurz.
Table 1‐1. ProgramModeFunctions(continued)
