Kurz B Series User Manual

KurzB‐SeriesOperationsGuide2–6
B‐SeriesFlowMeterDisplay Mode Options
Rectangle
DUCT WIDTH
>36.25 IN
DUCT Height
>40.625 IN
Round
INSIDE DIAMETER
>15.325 IN
8> PressPtocontinue.
FLOW AREA
>10.525 SQFT
9> PressPtocontinue.
PROBE DEPTH
>18.230 IN
Forinsertionflowmeters,theProbeDepthoptionappears.
10> PressPtocontinue.
ANALOG OUT 1
>FLOW RATE
TheAnalogOutputoptionsareflowrate,velocity,temperature,andPID.
11> PressPtocontinue.
AO1 at 4mA
>0.0000000 SCFM
Theanalogoutput4mApromptdeterminestheminimumrangevalueoftheprocess
variableassociatedwithanalogoutput1ofthemeter.Theflowunittyp ewasspecified
inapreviousoption.
12> PressPtocontinue.
AO1 at 20mA
>15000.000 SCFM
^
^
