KurzB‐SeriesOperationsGuide 2–7
B‐SeriesFlowMeterDisplay Mode Options
Theanalogoutput20mApromptdeterminesthemaximumrangevalueoftheprocess
variableassociatedwithanalogoutput1ofthemeter.Theflowunittyp ewasspecified
inapreviousoption.
13> PressPtocontinue.
Note:Iftheflowmeterwasconfiguredwithasecondanalogoutput,prompts
willappearforAO2at4mAandAO2at20mA.
RUN MODE DISPLAY
>STATIC
TheRunModeoptionsarestaticvariablesandscrolledvariables.
Referto“RunMode”onpage 1‐6 foradescriptionofstaticandscrolledmodes.
14> PressPtocontinue.
STATIC VARS
>FLOW+TEMP
Dependingontherunmodeselection,thestaticvariableorscrolledvariablesprompt
appears.
15> PressHtoexit.
ThemainDisplaymode(DSP)promptappears.
^
^
^
^
