2MY/2MZ-2
No. Content
Check procedure & check point
Remark 1
TASKalfa 256ci/FS-C8525MFP, TASKalfa 206ci/FS-C8520MFP,
TASKalfa 306i/FS-6530MFP, TASKalfa 256i/FS-6525MFP
F16X
An error is detected at the
KMAS control section
1) Check connection of the harness (KMAS - Main board) and connectors and check
function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and check
function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division.
(*1) For the HDD standard model only.
-
F17X
An error is detected at the print
data control section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and check
function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division.
(*1) For the HDD standard model only.
F18X
An error is detected at the
Video control secion
1) Check connection of the harness (Engine - Main board) and connectors and check
function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and check
function.
4) Replace the engine board and check function.
5) Replace the main board and check function.
6) Retrieve the USBLOG and contact the Service Administrative Division.
(*1) For the HDD standard model only.
<Monochrome models>
[Main-LSU Interface]
Main board: YC103
LSU(APC PWB): YC2
[Main-Engine Interface]
Main board: YC105
Engine board: YC17
<Color models>
[Main-LSU Interface]
Main board: YC104
LSU relay board: YC10
[Main-Engine Interface]
Main board: YC105
Engine board: YC26
[Relay connector]
Between the main board and the LSU relay board.
F19X
F1AX
F1BX
An error is detected at the
Security management section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and check
function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division.
.
An error is detected at the OS
or some of device drivers
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and check
function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division.
(*1) For the HDD standard model only.
2-4-13
