2GN/2GP/2GR-2
1-4-6
Feedshift
section
52
Misfeed in feedshift
section
The feedshift switch (FSSW) does not turn on within
specified time of the start of eject motor (EM) reverse
rotation.
1545 ms (30 ppm)/
1196 ms (40/50 ppm)
During paper switchback operation, the feedshift switch
(FSSW) does not turn off within specified time of the its
turning on.
2989 ms (30 ppm)/
2313 ms (40/50 ppm)
The feedshift switch (FSSW) does not turn off within
specified time of the registration switch (RSW) turning off.
2899 ms (30 ppm)/
2243 ms (40/50 ppm)
The feedshift switch (FSSW) does not turn off within
specified time of the registration clutch (RCL) turning on.
2899 ms (30 ppm)/
2243 ms (40/50 ppm)
Duplex
section
60
Duplex paper convey-
ing section 1
The duplex paper conveying switch (DUPPCSW) does
not turn on within specified time of the feedshift switch
(FSSW) turning on.
2837 ms (30 ppm)/
2196 ms (40/50 ppm)
The duplex paper conveying switch (DUPPCSW) does
not turn off within specified time of the feedshift switch
(FSSW) turning off.
2837 ms (30 ppm)/
2196 ms (40/50 ppm)
61
Duplex paper convey-
ing section 2
The feed switch 1 (FSW1) does not turn on within speci-
fied time of the duplex paper conveying switch (DUP-
PCSW) turning on.
1994 ms (30 ppm)/
1543 ms (40/50 ppm)
The feed switch 1 (FSW1) does not turn off within speci-
fied time of the duplex paper conveying switch (DUP-
PCSW) turning off.
1994 ms (30 ppm)/
1543 ms (40/50 ppm)
Optional
DP
70
No original feed
The original feed switch (OFSW) does not turn on within
specified time during the first sheet feeding.
2436 pulses
The original feed switch (OFSW) does not turn on within
specified time during the second sheet feeding.
4430 pulses
71
An original jam in the
original feed/conveying
section 1
DP timing switch 2 (DPTSW2) does not turn off within
specified time.
2500 pulses
72
An original jam in the
original feed/conveying
section 2
The original feed switch (OFSW) and original registration
switch (ORSW) does not turn off within specified time.
16675 pulses
73
An original jam in the
original conveying sec-
tion
DP timing switch 1 (DPTSW1) does not turn off within
specified time.
4979 pulses
74
An original jam in the
original registration
section
The original registration switch (ORSW) does not turn on
within specified time and after 5 retries.
4979 pulses
Optional
DP
75
An original jam in the
original registration
section
The original registration switch (ORSW) does not turn off
within specified time.
19533 pulses
DP timing switch 1 (DPTSW1) does not turn on within
specified time.
4979 pulses
76
An original jam in the
original feed/conveying
section
DP timing switch 2 (DPTSW2) does not turn on within
specified time.
2500 pulses
Section Description Conditions Specified time
