192 Multiplexing
Pump:BodyLower Switch ON Release BodyLower Switch prior to
Engaging Pump
Pump:BodyRaise Switch ON Release BodyRaiseSwitch prior to
Engaging Pump
Pump:CrusherDown Switch ON Release CrusherDown Switch prior
to Engaging Pump
Pump:CrusherUp Switch ON Release CrusherUp Switch prior to
Engaging Pump
Pump:Hopper Door Not Close Close Open Door
Pump:J1 AutoDump Switch ON Release J1 AutoDump Switch prior
to Engaging Pump
Pump:J1 ChuteToLeft Switch ON Release J1 ChuteToLeft Switch
prior to Engaging Pump
Pump:J1 ChuteToRight Switch ON Release J1 ChuteToRight Switch
prior to Engaging Pump
Pump:J1 CloseGripper Switch ON Release J1 CloseGripper Switch
prior to Engaging Pump
Pump:J1 Deadman Switch ON Release J1 Deadman Switch prior to
Engaging Pump
Pump:J1 OpenGripper Switch ON Release J1 OpenGripper Switch
prior to Engaging Pump
Pump:J2 AutoDump Switch ON Release J2 AutoDump Switch prior
to Engaging Pump
Pump:J2 ChuteToLeft Switch ON Release J2 ChuteToLeft Switch
prior to Engaging Pump
Pump:J2 ChuteToRight Switch ON Release J2 ChuteToRight Switch
prior to Engaging Pump
Pump:J2 CloseGripper Switch ON Release J2 CloseGripper Switch
prior to Engaging Pump
Pump:J2 Deadman Switch ON Release J2 Deadman Switch prior to
Engaging Pump
Pump:J2 OpenGripper Switch ON Release J2 OpenGripper Switch
prior to Engaging Pump
Table 1 Warning messages (cont’d)
