14 Safety
NOTE: The hydraulic tank model may vary according to the options installed on the vehicle.
3. Once the engine is started, wait for air pressure to build up to at least 70 psi.
Figure 2-4
Air pressure indicator
IMPORTANT: Do not operate or move the vehicle until air pressure has reached 70 psi.
4. Engage the hydraulic system by turning ON the Pump switch on the in-cab control panel
(see Figure 2-5).
Figure 2-5
Pump switch
• A green switch means the pump is active.
• A blue switch means the pump is not active.
Warning!
Failure to fully open the main valve will cause immediate damage to the pump, even if
the pump is turned off.
