General Maintenance 39
Figure 3-21
Hopper deflector & chute stopper assembly
Figure 3-22
Chute front support
1 g. Remove all bolts holding the chute shaft cover in place (see Figure 3-23).
1 h. Take off the chute shaft cover.
Deflector
Chute
stopper ass.
