54 General Maintenance
24. Tack weld both floor guides to the floor.
Figure 3-44
Tack weld on both sides of the floor guide
25. Start the truck and engage the hydraulic pump.
26. Retract the packer completely.
27. Turn OFF the hydraulic pump and the engine.
28. Lock out and tag out the vehicle (see Locking Out and Tagging Out the Vehicle on page 12).
29. Align the packer with the hopper walls.
30. Tack weld both floor guides to the floor in front of the packer.
31. Weld both sliding shoes to the packer.
Figure 3-45
View from behind fully retracted packer
Danger!
Never enter the hopper while the packer is moving.
Weld
here
