Step 2. Remove the GPU adapter from the riser bracket. See “Remove a PCIe adapter” on page 122.
If you are instructed to return the old GPU adapter, follow all packaging instructions and use any packaging
materials that are provided.
Install a GPU adapter
Use this information to install a GPU adapter.
“Read the
installation
Guidelines” on
page 79
“Power off
the server for
this task” on
page 11
“ATTENTION:
Static Sensitive Device
Ground package before opening”
on page 82
Notes:
• Only certain types of GPU adapters are supported, refer to “Specifications” on page 3 for detailed
information.
• GPU adapters are supported on some server models with requirements, refer to “Technical rules for GPU
adapters” on page 85.
To install a GPU adapter, complete the following steps:
Watch the procedure. A video of the installation and removal process is available:
• YouTube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-DTDY1lmpIPpJVOzo7dKq14
• Youku: http://list.youku.com/albumlist/show/id_52222446.html
Step 1. Locate the appropriate PCIe slot for the GPU adapter.
Step 2. Align the GPU adapter with the PCIe slot on the riser card. Then, carefully press the GPU adapter
straight into the slot until it is securely seated. See “Install a PCIe adapter” on page 125.
Step 3. Reinstall the riser assembly. See “Install a riser card” on page 120.
After installing the GPU adapter, complete the parts replacement. See “Complete the parts replacement” on
page 203.
Backplane replacement
Use this information to remove and install the backplane.
Remove the backplane for four 3.5-inch hot-swap drives
Use this information to remove the backplane for four 3.5-inch hot-swap drives.
“Read the
installation
Guidelines” on
page 79
“Power off
the server for
this task” on
page 11
“ATTENTION:
Static Sensitive Device
Ground package before opening”
on page 82
Before removing the backplane:
1. Remove the top cover. See “Remove the top cover” on page 89.
2. Remove all the installed drives and drive fillers from the drive bays. See “Remove a hot-swap drive” on
page 111 and “Install a hot-swap drive” on page 112.
Chapter 3. Hardware replacement procedures 131
