System board LEDs
The illustration in this section shows the LEDs on the system board.
Figure 16. System board LEDs
Table 12. LEDs on the system board
Callout Callout
1 BMC heart beat LED 2 System ID LED
3 System error LED 4 DIMM error LEDs (16)
5 Fan error LEDs (7)
1 BMC heart beat LED
The BMC heart beat LED helps you identify the BMC status.
