Lenovo ThinkSystem SR635 - Technical Rules for Drives

• Maximum TDP for CPU is 225 watts.
The following table lists the technical rules between NVIDIA Quadro P620 GPU adapters and processor TDP
for different configurations.
Supported configuration
for drives in front
backplane
NVIDIA Quadro P620 GPU
adapters
Processor TDP
Supported ambient
temperature
• 4 x 3.5-inch SAS/SATA
• 8 x 2.5-inch SAS/SATA
• 6 x 2.5-inch SAS/SATA
+ 4 x 2.5-inch AnyBay
• 10 x 2.5-inch AnyBay
3
120/155/180/200/225
watts
up to 35°C
Technical rules for drives
The following notes describe the types of drives that your server support and other information that you must
consider when you install a drive.
• Depending on your server models, your server supports the following types of drives:
– SAS/SATA HDD
– SAS/SATA SSD
– NVMe SSD
For a list of supported drives, see:
https://static.lenovo.com/us/en/serverproven/index.shtml
• The drive bays are numbered to indicate the installation order (starting from number “0”). Follow the
installation order when you install a drive. See “Front view” on page 13.
• You can mix drives of different types and different capacities in one system, but not in one RAID array.
The following priorities are recommended:
– Drive type priority: NVMe SSD, SAS SSD, SATA SSD, SAS HDD, SATA HDD
– Drive capacity priority: the lowest capacity first
• The drives in a single RAID array must be the same type, same size, and same capacity.
• If you select 12 or 14 TB 3.5-inch SAS/SATA drives, only standard fan is supported.
• For middle drive cage:
– Only NVMe drives are supported.
Note: Only 7 mm NVMe drives are supported based on thermal consideration.
– High-performance fan should be selected, and the supported ambient temperature is up to 30°C.
• For rear drive cage:
– Both SAS/SATA and NVMe drives are supported.
Note: For NVMe drives, only 7 mm NVMe drives are supported based on thermal consideration.
– High-performance fan should be selected, and the supported ambient temperature is up to 30°C.
– Supported processor TDP is 120/155 watts.
Chapter 3. Hardware replacement procedures 87
