Figure 130. SAS/SATA rear backplane connectors
1
SAS/SATA signal connector
2
Power connector
Step 4. Install the air baffle into the rear hot-swap drive cage as shown.
Figure 131. Air baffle installation
Step 5. Align the three pins on the rear hot-swap drive cage with the holes and slot in the chassis. Then,
lower the rear hot-swap drive cage into the chassis until it is fully seated.
