Figure 61. VGA/USB/Front panel connector cable routing for server model with four 3.5-inch drive bays
Cable
To
1 USB cable from the front of server Front USB connector on the system board
2 Front panel cable from the front of server Front Panel connector on the system board
3 VGA cable from the front of server Front VGA connector on the system board
The following is the cable routing for server model with eight/ten 2.5-inch drive bays.
Chapter 2. Server components 71
