6.4.3 User menu
The user menu can be freely configured in C00517 and contains the following parameters
in the Lenze setting:
Parameter
s
Name Info Lenze setting
C00011 Appl.: Reference speed Setting the reference speed 1500rpm
C00012 Accel. time − main
setpoint
FB L_NSet_1: Acceleration time of the ramp
generator for the main speed setpoint
2.0s
C00013 Decel. time − main
setpoint
FB L_NSet_1: Deceleration time of the ramp
generator for the main speed setpoint
2.0s
C00015 VFC: V/f base frequency V/f base frequency for VFCplus motor control 50Hz
C00016 VFC: Vmin boost Boost of the V/f voltage characteristic within the
range of low speed or frequency values for the
VFCplus motor control.
2.6%
C00022 Imax in motor mode Maximum current in motor mode for all motor
control modes
5.8A
C00039/1 Preset setpoint 1
(L_NSet_1 n−Fix)
FB L_NSet_1: Fixed speed setpoints (JOG values) for
the setpoint generator
Fixed setpoint 1
40.0%
C00039/2 Fixed setpoint 2 Fixed setpoint 2 60.0%
C00051 MCTRL: Actual speed
value
Actual speed value of the motor shaft ˘
C00053 DC−bus voltage Actual DC−bus voltage ˘
C00054 Motor current Current motor current/output current of the
inverter
˘
C00061 Heatsink temperature Current heatsink temperature ˘
C00087 Rated motor speed This value can be obtained from the motor
nameplate. After the motor to be used has been
selected from the motor catalogue, the suitable
value can be entered automatically.
1320rpm
C00099 Firmware version Firmware version of the device as string ˘
C00105 Decel. time − quick stop The set deceleration time determines the ramp
slope at quick stop
5.0s
C00120 Motor overload
threshold (I
2
xt)
Operating threshold for the error message "OC6:
Motor overload (I
2
xt)"
100%
C00137 Device status Current device state ˘
C00166/3 Mess. − status det. error Textual message of the currently pending error ˘
C00173 Mains voltage Selection of the mains voltage for operating the
device.
0: "3ph 400V"
C00200 Firmware product type ˘
˘ Read only
