Commissioning
Commissioning via the diagnosis terminal
Commissioning steps
6
l
141
EDS84DG752 EN 7.0
6.4.4 Commissioning steps
) Note!
The following can be connected to the X70 diagnostic interface:
ƒ USB diagnostic adapter (E94AZCUS)
ƒ X400 diagnosis terminal (EZAEBK200x)
– The functions of the X400 diagnosis terminal and keypad (EZAEBK100x)
are identical.
Only some parameters must be adapted for the drive. Then the drive application can be
controlled immediately in the preset "Terminals 0" control mode via the digital and analog
inputs. Alternatively, the keypad can be used for defining the required setpoints and
control signals in the "Keypad" control mode.
How to proceed:
1. Wiring of power terminals
– Make use of the mounting instructions supplied with the inverter to wire the
power terminals according to the requirements of your device.
2. Wiring of control terminals.
– The preconfigured I/O connection can be changed via configuration parameters.
See the "User−defined terminal assignment" chapter.
– Assignment in the preset "Terminals 0" control mode:
