9.1.4 Frame Unit with switch
The Frame Unit with switch is a wiring and switch box for wall mounting and a power class
up to 3.0kW. The Frame Unit with switch is available in the following combinations:
ƒ Design with cable gland
ƒ Design with plug, 2 × HAN Q4/2 for establishing a mains cable loop−through
connection and 1 × HAN Q8 for implementing the motor connection
ƒ With service switch
ƒ With service switch and control elements
ƒ With service switch and protective function
E84DG129
