Commissioning
Commissioning via DIP switch/potentiometer
6
l
125
EDS84DG752 EN 7.0
6.3 Commissioning via DIP switch/potentiometer
( Stop!
Automatic motor start
In "Local mode" The auto−start option "Inhibit at power−on" is not set. When
the mains is connected, the motor starts if the controller enable RFR is bridged
or set.
("Local mode" => DIP1/1 = ON and DIP2/5−7 = OFF)
Possible consequences:
ƒ Danger or damages through unexpected motor start.
Protective measures:
ƒ Decouple the motor from the drive train during commissioning phase.
ƒ Replace the factory−set bridge at RFR by an NO contact.
ƒ Do not set controller enable.
For initial commissioning, settings can be made via DIP switch and potentiometer. The
settings must be made before mounting the drive unit since the setting elements cannot
be accessed from the outside.
From software version 07.00.00 onwards, you can use DIP2/8 to set two different
pre−assignments of DIP1, DIP2, P1, P2, and P3:
ƒ DIP2/8=OFF: DIP switch/ potentiometer assignment 0
ƒ DIP2/8=ON: DIP switch/ potentiometer assignment 1
Up to software version 07.00.00, only DIP switch/ potentiometer assignment 0 is available.
