9.4 Diagnosis terminal
The X400 diagnosis terminal is a simple means for parameter setting and diagnostics on
site. Clearly structured menus and a plain text menu provide for quick data access. The
diagnosis terminal is connected to the X70 diagnostic interface. The diagnosis terminal is
based on the X400 keypad, extended by a holder and a connecting cable.
Mode Features Diagnosis terminal
Diagnosis
terminal
EZAEBK2003
l 2.5m connecting cable, exchangeable
l Menu−driven diagnostics and parameter
setting
l Backlighted graphic display for representing
information
l 4 navigation keys, 2 context−sensitive keys
l Adjustable RUN/STOP function
l Supports hot plugging
l Enclosure IP20
