Technical data
8400 motec Field Package
8400 motec 4...7.5kW
4
l
60
EDS84DG752 EN 7.0
Motor holding brake
Terminal data
Name Power Conductor cross−section
[mm
2
]
[AWG]
Tightening torque
[Nm]
[lb−in]
!
X1
BD1 (+)
BD2 (−)
˘ 1.5
16
0.5
4.4
3.5 x 0.6
Features
Name Description Rated value
X1
BD1 (+)
BD2 (−)
Connection of a motor holding brake
Output voltage
(depending on the mains voltage)
DC 180 V
DC 215 V
Max. output current 0.3 A
Max. output power 55 VA
Time−dependent behaviour See software manual, chapter "Holding brake
control/parameter setting"
Short−circuit−proof No
Reset and switch−on behaviour Outputs are switched off
Operating frequency Max. 30/min
Brake resistor
Terminal data
Name Power Conductor cross−section
[mm
2
]
[AWG]
Tightening torque
[Nm]
[lb−in]
!
X1
Rb1, Rb2 ˘ 1.5
16
0.5
4.4
3.5 x 0.6
Features
Name Description Rated value
X1
Rb1, Rb2
Brake resistor See rated data
