Parts catalog 7-1
7002-xxx
7. Parts catalog
How to use this parts catalog
The following legend is used in the parts catalog:
• Asm-index: identifies the assembly and the item in the diagram. For example, 3-1 indicates Assembly 3
and the item number 1.
• Part number: identifies the unique number that identifies this FRU.
• Units/mach: refers to the number of units actually used in the base machine or product.
• Units/option: refers to the number of units used in the option and does not include the base machine.
• Units/kit or pkg: refers to the number of units packaged together and identified by the part number.
• PP: (Parts Packet) in the parts description column indicates the part is contained in a parts packet.
• NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
• NA: (Not available) in the parts description column indicates the part is shown for identification purposes
only and is not available as a FRU.
Model information used in the parts catalog.
Asm-
Index
Part
number
Units/mach
- OR -
Units/option
Units/
kit or
pkg
Description
Model name Configuration Machine type Parts catalog
Lexmark X644e Network 7002-001 001
Lexmark X642e Network 7002-003 003
Lexmark X642e Network, modem 7002-005 005
Lexmark X644e Network, modem 7002-011 011
Lexmark X646e Network, hard disk 7002-101 101
Lexmark X646e Network, modem, hard disk 7002-111 111
Lexmark X644e HV, network 7002-002 002
Lexmark X642e HV, network 7002-004 004
Lexmark X642e HV, network, modem 7002-006 006
Lexmark X644e HV, network, modem 7002-012 012
Lexmark X646e HV, network, hard disk 7002-102 102
Lexmark X646e HV, network with hard disk 7002-112 112
