Lexmark X642e - Assembly 26: Cabling Diagram 3

Parts catalog 7-45
7002-xxx
Assembly 26: Cabling diagram 3
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
26—1 40X0034 1 1 Signature button contact assembly with cable
2 40X0156 1 1 Bottom/front autoconnect cable assembly
3 40X0223 1 1 HVPS/input sensor/toner sensor cable assembly
4 40X0224 1 1 LVPS to system board cable assembly
